+# Boot process
+
+[//]: # ----------------------------------------------------------------
+## Boot loader
+
+- **Purpose of a bootloader**:
+	- basic hardware initialization
+	- loading of an application binary, usually a kernel from storage, network, etc.
+	- execution of the binary
+
+\vspace{.3cm}
+
+- Most bootloaders provide a shell with various commands:
+	- loading data from storage or network, memory inspection, boot kernel, hardware diagnostics, etc.
+
+[//]: # ----------------------------------------------------------------
+## BIOS and UEFI
+
+- **BIOS** (Basic Input/Output System) is the old historical PC firmware
+  - executed in 16-bit mode (*real mode*) with 1MB of address space
+  - very basic services and only usable in 16-bit mode
+
+\vspace{.3cm}
+
+- **UEFI** (Unified Extensible Firmware Interface) is BIOS' successor
+  - executed in either 32 or 64-bit mode
+  - features many services and modules
+  - highly complex (specs are 4k+ page long)
+  - BIOS-compatible mode called *legacy mode*
+
+\vspace{.3cm}
+- BIOS and UEFI are stored in non-volatile memory (e.g. flash)
+
+<!--
+[//]: # ----------------------------------------------------------------
+## BIOS boot process stages (x86)
+
+:::::: {.columns}
+::: {.column width="70%"}
+
+\small
+
+\vspace{.8cm}
+
+1. BIOS is executed after reset $\rightarrow$ responsible for basic hardware initialization
+1. Searches for a bootable device by loading the first sector (512 bytes) of each storage device until finding a valid signature: `0x55AA` at offset 510
+1. This 510 bytes code is usually the "stage1" bootloader which loads "stage2"
+1. "stage2" is much larger, switches CPU to 32-bit mode and typically understands filesystems so kernel can be loaded directly from a filesystem
+
+:::
+::: {.column width="30%"}
+
+\centering
+![](images/x86_bootloader.png){ width=80% }
+
+:::
+::::::
+-->
+
+[//]: # ----------------------------------------------------------------
+## UEFI boot process (x86)
+
+- UEFI loads and executes an arbitrary sized UEFI application from an EFI System Partition (ESP)
+  - This application must reside in a certain location in the filesystem e.g. `/efi/BOOT/BOOTX64.EFI` on a x86-64 PC
+- An UEFI-compliant boot device must have a GUID Partition Table (GPT) that specifies an ESP
+  - This ESP must be formatted with the FAT filesystem
+- UEFI can boot in "legacy mode" to boot on legacy software written for BIOS
+
+<!--
+[//]: # ----------------------------------------------------------------
+## MBR partition table (BIOS)
+
+![](images/part_table_mbr.png){ width=100% }
+
+\vfill
+\tiny
+Source: [\textcolor{myblue}{https://en.wikipedia.org/wiki/Master\_boot\_record}](https://en.wikipedia.org/wiki/Master_boot_record)
+
+[//]: # ----------------------------------------------------------------
+## GUID partition table (UEFI)
+
+\centering
+![](images/part_table_gpt.png){ width=90% }
+
+\vfill
+\tiny
+\centering
+Source: [\textcolor{myblue}{http://www.ntfs.com/guid-part-table.htm}](http://www.ntfs.com/guid-part-table.htm)
+-->
+
+[//]: # ----------------------------------------------------------------
+# GRUB
+
+[//]: # ----------------------------------------------------------------
+## Multiboot specification
+
+- Open specification defining how a bootloader may load a kernel
+
+- **Goals**
+  - Allow any bootloader to load any compatible OS $\rightarrow$ guarantee **interoperability**
+  - Allow to boot **multiple** OS on the same machine
+
+- Reference: \footnotesize [\textcolor{myblue}{https://www.gnu.org/software/grub/manual/multiboot/multiboot.html}](https://www.gnu.org/software/grub/manual/multiboot/multiboot.html)
+
+[//]: # ----------------------------------------------------------------
+## The “**GR**and **U**nified **B**ootloader” (GRUB)
+
+- GRUB is a powerful and versatile bootloader able to boot multiple OS
+- Implements the multiboot specification
+- Features:
+  - shell allowing user interaction
+  - on-the-fly changes to the boot configuration
+  - ability to load modules at runtime to extend its capabilities
+  - configuration file (`grub.cfg`) to configure its behavior
+- Open source GNU project (GPL 3.0 license)
+- Latest version is GRUB 2
+
+[//]: # ----------------------------------------------------------------
+## GRUB boot process
+
+\small
+
+GRUB is a *chain bootloader* $\rightarrow$ multiple stage initialization:
+
+- **Stage1**: located in sector 0, loaded in RAM by BIOS/UEFI
+  - \footnotesize stage1 image usually in `/boot/grub/i386-pc/boot.img`
+  - contains code required to load stage2
+
+\vspace{.3cm}
+
+- **Stage2**: max 32KB, located in first sectors, loaded by stage1
+  - \footnotesize stage2 image usually in `/boot/grub/i386-pc/core.img`
+  - contains drivers required to access the filesystem (`/boot/grub/grub.cfg`, grub modules, kernel image)
+  - displays the GRUB menu interface and command prompt
+  - able to load an OS **located on a filesystem**
+
+[//]: # ----------------------------------------------------------------
+## Example: Linux kernel boot process
+
+\centering
+![](images/linux_kernel_boot.png){ width=95% }
+
+[//]: # ----------------------------------------------------------------
+## System state at boot
+
+- GRUB switches CPU to 32-bit (protected mode)
+
+- GRUB initializes CPU and its own GDT (memory mapping)
+
+  - See “Machine state” in multiboot specification: \tiny [\textcolor{myblue}{https://www.gnu.org/software/grub/manual/multiboot/multiboothtml\#Machine-state}](https://www.gnu.org/software/grub/manual/multiboot/multiboothtml#Machine-state)
+
+- \normalsize GRUB stores in `EBX` register, the address of a structure containing info detected at boot time (RAM, etc.) and GRUB info (modules, cmd line, etc.)
+  - This structure is `multiboot_info_t` and is defined in `multiboot.h`
+  - Content of `multiboot.h`: \tiny [\textcolor{myblue}{http://git.savannah.gnu.org/cgit/grub.git/tree/doc/multiboot.h?h=multiboot}](http://git.savannah.gnu.org/cgit/grub.git/tree/doc/multiboot.h?h=multiboot)
+
+[//]: # ----------------------------------------------------------------
+## Example of "empty" bootstrap code loaded by GRUB
+
+```{.tiny .assembler}
+; Values for the multiboot header
+MULTIBOOT_MAGIC        equ 0x1BADB002  ; multiboot magic value
+MULTIBOOT_ALIGN        equ 1   ; load kernel and modules on page boundary
+MULTIBOOT_MEMINFO      equ 2   ; provide kernel with memory info
+
+MULTIBOOT_FLAGS        equ (MULTIBOOT_ALIGN|MULTIBOOT_MEMINFO)
+
+; Magic + checksum + flags must equal 0!
+MULTIBOOT_CHECKSUM     equ -(MULTIBOOT_MAGIC + MULTIBOOT_FLAGS)
+
+section .multiboot
+
+; Mandatory part of the multiboot header
+dd MULTIBOOT_MAGIC
+dd MULTIBOOT_FLAGS
+dd MULTIBOOT_CHECKSUM
+
+entrypoint:
+	; Bootloader code starts executing here
+	cli  ; disable hardware interrupts
+
+.forever:
+	hlt
+	jmp .forever
+```
+
+[//]: # ----------------------------------------------------------------
+## Booting on a custom OS
+
+::: incremental
+
+How to boot on a custom OS?
+
+- Easiest way is to store the OS in a ISO image
+- ISO 9660 is a filesystem standard designed for optical disks (CD-ROM, DVD-ROM, etc.)
+- ISO 9660  image = image of a read-only filesystem to be stored on a CD-ROM to be booted on
+- An ISO image can be "flashed" on a USB key (e.g. with `dd`) to make it bootable
+- For an ISO image to be bootable, GRUB must be installed in the first sectors (in the first 8KB)
+
+:::
+
+[//]: # ----------------------------------------------------------------
+## ISO image generation
+
+\footnotesize
+
+How to create an ISO image bootable with GRUB and containing `kernel.elf`?
+
+\vspace{.2cm}
+
+:::::: {.columns}
+::: {.column width="40%"}
+
+Prepare this file structure:
+```{.verysmall}
+build/
+`-- boot
+    |-- grub
+    |   `-- grub.cfg
+    `-- kernel.elf
+```
+
+:::
+::: {.column width="50%"}
+
+Content of `grub.cfg`:
+```{.verysmall}
+set timeout=1
+
+menuentry "MyOS" {
+  multiboot /boot/kernel.elf
+}
+```
+
+:::
+::::::
+
+- Where:
+  - `build` is the root directory used for the ISO image
+  - `grub.cfg` is the GRUB configuration
+  - `kernel.elf` is the kernel to boot
+
+- To create the `myos.iso` image, run:
+  ```{.verysmall}
+  grub-mkrescue /usr/lib/grub/i386-pc -o myos.iso build
+  ```
+
+[//]: # ----------------------------------------------------------------
+## Required Ubuntu packages
+
+To run `grub-mkrescue` on a Ubuntu system, the following packages are **required**:
+
+- `grub-common`
+- `grub-pc-bin`
+- `xorriso`
+- `mtools`
+
+[//]: # ----------------------------------------------------------------
+## Multiboot boot modules
+
+- The multiboot specification allows a bootloader to automatically load arbitrary files into memory (RAM)
+- These files are called "boot modules"
+  - they can have a command line, retrievable by the kernel
+- GRUB can automatically load such boot modules into RAM
+- Each file's content can then be addressed by the kernel
+- The kernel only needs to know:
+  - at which address a boot module is loaded
+  - the module's length
+  - if needed: the module's command line
+- Luckily, these information are provided by GRUB!
+
+[//]: # ----------------------------------------------------------------
+## Boot modules example
+
+Below, we tells GRUB to load 2 boot modules: `prog` and `logo.png`:
+
+\vspace{.2cm}
+
+:::::: {.columns}
+::: {.column width="50%"}
+
+```{.verysmall}
+set timeout=1
+
+menuentry "MyOS" {
+  multiboot /boot/kernel.elf
+  module /bin/prog arg1 arg2
+  module /data/logo.png
+}
+```
+
+:::
+::: {.column width="40%"}
+
+```{.verysmall}
+build/
+`-- boot
+ |  |-- grub
+ |  |   `-- grub.cfg
+ |  `-- kernel.elf
+ |--bin
+ |  `-- prog
+ `--data
+    `-- logo.png
+```
+
+:::
+::::::
+
+[//]: # ----------------------------------------------------------------
+## Multiboot structure
+
+- The multiboot specification defines a set of information that can be retrieved by the kernel (or any executable binary loaded by the bootloader)
+- These information are stored in the `multiboot_info_t` structure defined in `multiboot.h`
+- Examples of information available in the structure:
+  - RAM available on the system
+  - kernel command line
+  - number of boot modules
+  - address and length of each boot module
+  - framebuffer address
+  - horizontal display resolution
+  - etc.
+
+[//]: # ----------------------------------------------------------------
+## Multiboot structure: important remarks
+
+- Many `multiboot_info_t` fields are defined as `multiboot_uint32_t`
+- However, often they simply represent 32-bit addresses (since the CPU is in 32-bit mode, addresses are 32 bits long)
+- Reminder:
+  - if a CPU uses 32 bits addresses, then a 32-bit integer can be used as an address
+  - in C, the value of a pointer is an address, thus an integer
+- Therefore, it's up to you to cast these 32-bit integers to whatever pointer type is needed
+
+[//]: # ----------------------------------------------------------------
+## Boot modules information (1/2)
+
+- The `multiboot_info_t` structure stores everything about boot modules in these members:
+  - `mods_count`: number of boot modules loaded by GRUB
+  - `mods_addr`: address of the first loaded module; this member is of the type `(multiboot_module_t *)`
+
+\vspace{.3cm}
+
+- Then, for each module (of type `multiboot_module_t *`):
+  - `mod_start`: address where the module content starts (inclusive)
+  - `mod_end`: address where the module content ends (non-inclusive)
+  - The memory content range of the module is then: `[mod_start, mod_end[`
+  - `cmdline`: address of the module command line (`"arg1 arg2"` for module `prog` in the previous example)
+
+[//]: # ----------------------------------------------------------------
+## Boot modules information (2/2)
+
+- `mods_addr` can be seen as an array of `multiboot_module_t` elements
+- The size of this array is `mods_count`
+- Each module's command line is simply a C string, thus an address pointing to the first character of the command line
+  - the end of the command line is marked with the value 0
+
+[//]: # ----------------------------------------------------------------
+## Resources
+
+\small
+
+- Booting Linux on x86 using Grub2\
+\footnotesize [\textcolor{myblue}{http://moi.vonos.net/linux/Booting\_Linux\_on\_x86\_with\_Grub2/}](http://moi.vonos.net/linux/Booting_Linux_on_x86_with_Grub2/)
+
+\small
+
+- Multiboot2 Specification version 2.0\
+\footnotesize [\textcolor{myblue}{https://www.gnu.org/software/grub/manual/multiboot2/multiboot.html}](https://www.gnu.org/software/grub/manual/multiboot2/multiboot.html)
+
+\small
+
+- GNU GRUB Manual 2.04\
+\footnotesize [\textcolor{myblue}{https://www.gnu.org/software/grub/manual/grub/grub.html}](https://www.gnu.org/software/grub/manual/grub/grub.html)
+
+\small
+
+- GRUB 2 on a lower level\
+\footnotesize [\textcolor{myblue}{http://www.dolda2000.com/~fredrik/doc/grub2}](http://www.dolda2000.com/~fredrik/doc/grub2)

course/02-VBE_display.md

+---
+author: Florent Gluck - Florent.Gluck@hesge.ch
+
+title: VBE Display
+
+date: \vspace{.5cm} \footnotesize \today
+
+pandoc-latex-fontsize:
+  - classes: [tiny]
+    size: tiny
+  - classes: [verysmall]
+    size: scriptsize
+  - classes: [small]
+    size: footnotesize
+  - classes: [huge, important]
+    size: huge
+---
+
+[//]: # ----------------------------------------------------------------
+## PC graphics history
+
+:::::: {.columns}
+::: {.column width="70%"}
+
+\small
+
+- Original PC didn't feature any graphics mode: only character display (text)
+  - Most popular: VGA text mode: 80 col. by 25 rows, 16 colors
+- Over time, many graphics cards developped
+  - CGA ('81), EGA, VGA ('87), SVGA, etc.
+- No GPU back then, everything done by CPU
+  - First mainsteam GPU: 3dfx Voodoo ('95)
+- Every graphics card is programmed differently $\rightarrow$ very demanding
+  - Modern GPU are incredibly more complex and difficult to program
+
+:::
+::: {.column width="30%"}
+
+\vspace{.1cm}
+![](images/monkey_cga.png){ width=100% }
+![](images/monkey_ega.png){ width=100% }
+![](images/monkey_vga.png){ width=100% }
+
+:::
+::::::
+
+[//]: # ----------------------------------------------------------------
+## PC graphics today
+
+- For **compatibility reasons**, all modern PCs' graphics cards still support:
+  - VGA text mode
+  - VGA graphics modes (320x200 8bpp, 640x480 4bpp)
+  - Easy to program VGA text mode and VGA graphics modes
+    - but very dated...
+- Anything higher resolution and bit depth is hardware dependent
+- That's where VESA BIOS Extensions comes in
+
+[//]: # ----------------------------------------------------------------
+## VESA BIOS Extensions (VBE)
+
+- Goal was to provide a **hardware-independent** way of accessing graphics cards
+- VBE is a **standard** that defines the interface to access video cards at high resolutions and bit depths
+  - typically 640x480, 800x600, 1024x768, 1280x1024 in 8bpp, 16bpp, 24bpp and 32bpp
+  - provide access to hardware accelerated features (scrolling, sprites, blitter, drawing, etc.)
+- However, VBE can be very **tricky to initialize**
+- Luckily...
+
+[//]: # ----------------------------------------------------------------
+## GRUB to the rescue
+
+- Multiboot bootloaders (such as GRUB) implement VBE 3.0 graphics initialization
+- We can specify a *preferred* video mode
+- However, no guarantee: the bootloader might use a different video mode
+- The multiboot structure features details about the graphics mode set by the bootloader
+
+[//]: # ----------------------------------------------------------------
+## Example of bootloader requesting video mode
+
+\fontsize{6}{6}
+```{.assembler}
+MULTIBOOT_MAGIC        equ 0x1BADB002  ; multiboot magic value
+MULTIBOOT_ALIGN        equ 1   ; load kernel and modules on page boundary
+MULTIBOOT_MEMINFO      equ 2   ; provide kernel with memory info
+MULTIBOOT_VIDEO_MODE   equ 4   ; ask grub to switch to VBE graphics modes
+
+MULTIBOOT_FLAGS     equ (MULTIBOOT_ALIGN|MULTIBOOT_MEMINFO|MULTIBOOT_VIDEO_MODE)
+MULTIBOOT_CHECKSUM  equ -(MULTIBOOT_MAGIC + MULTIBOOT_FLAGS)
+
+section .multiboot
+
+; Mandatory part of the multiboot header
+dd MULTIBOOT_MAGIC
+dd MULTIBOOT_FLAGS
+dd MULTIBOOT_CHECKSUM
+
+; for MULTIBOOT_MEMORY_INFO
+dq 0x0000000000000000    ; header_addr + load_addr
+dq 0x0000000000000000    ; load_end_addr + bss_end_addr
+dd 0x00000000            ; entry_addr
+
+; for MULTIBOOT_VIDEO_MODE
+dd 0x00000000    ; mode_type
+dd 1024          ; width
+dd 768           ; height
+dd 32            ; depth
+
+entrypoint:
+	cli  ; disable hardware interrupts
+
+.forever:
+	hlt
+	jmp .forever
+```
+
+[//]: # ----------------------------------------------------------------
+## Multiboot structure: major video mode fields
+
+| **Field**            | **Description** |
+|---                   |---          |
+| `framebuffer_addr`   | physical address of the framebuffer |
+| `framebuffer_pitch`  | framebuffer pitch in **bytes** |
+| `framebuffer_width`  | framebuffer width in **pixels** |
+| `framebuffer_height` | framebuffer height in **pixels** |
+| `framebuffer_bpp`    | number of **bits** per pixel |
+
+Note: here, we ignore palletized video modes (typically 8bpp).
+
+[//]: # ----------------------------------------------------------------
+## Framebuffer layout
+
+\centering
+![](images/framebuffer.png){ width=95% }
+
+\vspace{.2cm}
+
+\scriptsize
+**Beware**: `framebuffer_pitch` is in **bytes** whereas `framebuffer_width` is in **pixels**!
+
+[//]: # ----------------------------------------------------------------
+## Pixel addressing
+
+- \textcolor{myred}{We must \textbf{always} use the pitch to calculate the pixel address, not the width!}
+- How to convert a 2D pixel position into a 1D memory address?
+- General formula, given a position (x,y) in pixels:
+  ```{.small}
+  pixel_address = framebuffer_address + y * pitch_in_pixels + x
+  ```
+  Beware: above, pitch is in pixels, not in bytes!
+
+[//]: # ----------------------------------------------------------------
+## Resources
+
+- VESA BIOS Extensions on Wikipedia\
+\scriptsize [\textcolor{myblue}{https://en.wikipedia.org/wiki/VESA\_BIOS\_Extensions}](https://en.wikipedia.org/wiki/VESA_BIOS_Extensions)
+
+\normalsize
+\vspace{.3cm}
+
+- VBE 3.0 specification\
+\scriptsize [\textcolor{myblue}{http://www.petesqbsite.com/sections/tutorials/tuts/vbe3.pdf}](http://www.petesqbsite.com/sections/tutorials/tuts/vbe3.pdf)
+
+\normalsize
+\vspace{.3cm}
+
+- Multiboot Specification: Boot information format\
+\scriptsize [\textcolor{myblue}{https://www.gnu.org/software/grub/manual/multiboot/multiboot.html\#Boot-information-format}](https://www.gnu.org/software/grub/manual/multiboot/multiboot.html#Boot-information-format)

course/Makefile

+SRCS=$(wildcard *.md)
+PDFS=$(SRCS:%.md=%.pdf)
+UID=$(shell id -u)
+GID=$(shell id -g)
+
+all: $(PDFS)
+
+%.pdf: %.md
+	docker run --user $(UID):$(GID) --rm --mount type=bind,src="$(PWD)",dst=/src thxbb12/md2pdf build_slides $<
+
+clean:
+	rm -f $(PDFS)
